DT-4500 Series C- and Ku-Band Down Converters MN/DT4500.IOM
Specifications Revision 2
2–6
CEFD P/N
Impedance
(Ohms)
Comments
AS/0101-31 75 DT-4513, UT-4514/F w/Isolator, Type ‘SMA’
AS/0101-32 50 DT-4513, UT-4514/F w/Isolator, Type ‘SMA
AS/0101-33 75 DT-4513, UT-4518/F w/Isolator, Type ‘SMA’
AS/0101-34 50 DT-4513, UT-4518/F w/Isolator, Typr ‘SMA’
AS/0101-41
50
DT-4513 1:1 Switching
2.1.8.5.5 RSM (Receive Switch Module) Assemblies
CEFD P/N
Impedance
(Ohms)
Comments
AS/0101-4
75
DT-4503 Switching, Down, Type ‘SMA’
AS/0101-6
75
DT-4503, DT-4572, UT-4579 Switching, Type ‘N’
AS/0101-7
50
DT-4503, DT-4572, UT-4579 Switching, Type ‘N’
AS/0101-16
50
DT-4503 I/O, Type ‘SMA’
AS/0101-20
75
Receive Switch, RSM2
AS/0101-26
50
RSM2, Type ‘N’
AS/0101-37
50
DT-451X w/Isolator, Type ‘SMA’
AS/0101-38 75 DT-451X w/Isolator, Type ‘SMA’
2.2 Operational Specifications
2.2.1 Available Models / Operating Frequency Ranges
Contact Comtech EF Data Product Support for your specific requirements.
2.2.1.1 C-Band Units
• DT-4503: 3625 to 4200 MHz
• DT-4503/C: 3400 to 4200 MHz
• DT-4503/D: 3400 to 3700 MHz
• DT-4503/E: 4500 to 4800 MHz
2.2.1.2 Ku-Band Units
• DT-4510: 10.95 to 11.70 GHz
