Comtech EF Data DT-4500 Series - Slope; Image Rejection; AM to PM; IF Bandwidth

DT-4500 Series C- and Ku-Band Down Converters MN/DT4500.IOM
Specifications Revision 2
2–10
2.2.9.5 Slope
0.05 dB/MHz
2.2.9.6 Image Rejection
-80 dB Inband
2.2.9.7 AM to PM
0.1°/ dB for Output up to -5 dBm
2.2.9.8 IF Bandwidth
Contact Comtech EF Data Product Support for your specific requirements.
• STANDARD: 36 or 72 MHz
• OPTIONAL: 40 or 80 MHz
2.2.10 Group Delay
2.2.10.1 Linear
0.03ns/MHz
2.2.10.2 Parabolic
0.01ns/MHz
2
2.2.10.3 Ripple
1.0ns Peak-to-Peak
