8.7.5 Status Queries
Status queries retrieve configuration, maintenance and alarm status in summary
form.
8.7.5.1 RCS (Configuration Status)
Description
Details
Configuration Status:
<DEV/RCS_{cr}
Confirmation:
>DEV/RCS_{cr}
FRE_xxxxx.xxx{cr} Frequency
ATT_yy.yy{cr} Attenuation
TX_nnn{cr} Transmitter: ON/OFF/COLD
ONL_nnn{cr} Online: ON/OFF
RED_xx_yy_z{cr} See Note
CLD_nnn{cr} Cold Start: ON/OFF
AFR_nnn{cr} Auto Flt Recovery: ON/OFF
EXT_xxx{cr}{lf}] Ext. Ref.: YES/NO
If Redundancy=OFF, then xx_yy_z = OFF; otherwise, if Redundancy=ON
and you select a converter as a backup controller: xx_yy_z = BU_yy,
where yy is the number of converters in the chain (i.e. 01 to 12).
Alternately, if Redundancy=ON and you select a converter as a chain
unit, where xx is the converter number (01 to 12), and z = A (if Auto
Mode) or M (if Manual Mode).
8.7.5.2 RMS (Maintenance Status)
Description
Details
Maintenance Status:
<DEV/RMS_{cr}
Confirmation:
>DEV/RMS_{cr}
P15_xx.x{cr} 15V DC Supply
P14_xx.x{cr} 14V DC Supply
VCC_x.x{cr} VCC Supply
5VD_x.x{cr} Display 5V DC
TEM_xx{cr} Temperature
IFL_xx.x{cr} IFLO Tuning
SUM_xx.x{cr} Sum Loop Tuning
COR_xx.x{cr} Coarse Loop Tune
FIN_xx.x{cr}{lf}] Fine Loop Tuning
