Comtech EF Data DT-4500 Series - Removable Module Connectors; Table 4-6. J3 | HSB Data Interface Pinout

DT-4500 Series C- and Ku-Band Down Converters MN/DT4500.IOM
Front and Rear Panel Connectors Revision 2
4–17
4.2.4.1 Removable Module Connectors
The module connector types vary depending on the operating band and
impedance of the purchased unit:
• The IF Input/Output and LP (Loop) In/Out connectors are typically female
BNC connectors.
• The RF Input/Output and LP (Loop) In/Out connectors may be female
Type ‘N’ or female Type ‘SMA’ connectors, depending on the application.
• All switch modules feature a ‘J3 | HSB’ (High Speed Bus) connector.
Table 4-6 provides the pinout specifications for this D-Sub 25-pin female
(DB-25F) connector. The mating connector is a DB-25M connector.
Table 4-6. ‘J3 | HSB’ Data Interface Pinout
Pin # Description
1 Cntl_12
2
Cntl_10
3
Cntl_8
4
Cntl_6
5 Cntl_4
6 Cntl_2
7
Cntl_In
8 +14V Out
9 +14V In
10 Aux_3
11 Aux_1
12
-Rx/Tx
13
GND
14 Cntl_11
15 Cntl_9
16
Cntl_7
17 Cntl_5
18 Cntl_3
19 Cntl_1
20 +14V Out
21
+14V In
22
GND
23
Aux_2
24 GND
25 +Rx/Tx
