DT-4500 Series C- and Ku-Band Down Converters MN/DT4500.IOM
Specifications Revision 2
2–8
2.2.7.2 Return Loss
20 dB minimum with I/O Module
2.2.7.3 Impedance
50Ω
2.2.7.4 Noise Figure
11 dB Maximum @ 0 dB Attenuation
2.2.8 IF Output
2.2.8.1 Level
+20 dBm @ 1 dB Compression
2.2.8.2 Range
Contact Comtech EF Data Product Support for your specific requirements.
• STANDARD: 50 to 88 MHz or 104 to 176 MHz
• OPTIONAL: 50 to 80 MHz or 100 to 180 MHz
2.2.8.3 Non-carrier Spurious
-80 dBm
2.2.8.4 Carrier Spurious
-65 dBc @ 0 dBm output
