Comtech EF Data DT-4500 Series - PACRUS (Packed Utility Status)

DT-4500 Series C- and Ku-Band Down Converters MN/DT4500.IOM
Serial Interface Operation Revision 2
8–31
k = 1 if EXT REF Fault, else 0 if No Fault
8.7.5.10 PACRUS (Packed Utility Status)
Description
Details
Utility Status:
<DEV/PACRUS_{cr}
Confirmation:
>DEV/PACRUS_ abbcdeeffghhii{cr}{lf}] where:
a = 0=EIA-232, 1=EIA-485
bb = Address in hex (01 to FF)
c = 0 if Baud Rate 38400
= 1 if Baud rate 19200
= 2 if Baud rate 9600
= 3 if Baud rate 4800
= 4 if Baud rate 2400
= 5 if Baud rate 1200
d = 0 if Data Format 8-N-1
= 1 if Data Format 7-E-2
= 2 if Data Format 7-O-2
ee = Osc. Adjust in hex (00 to FF)
ff = Slope Adjust times by 10 (00 to 10)
g = Always 0, unused
hh = LCD Contrast (0 to 30)
ii = LCD Brightness (0 to 30
