Maintenance 8-21
Replacing the Scanner Lamp-unit:
On Scanners: HD4230i
1. Turn the scanner power off and disconnect the power plug.
2. The lamp cover is on the top right side of the scanner.
Lamp cover
3. Grasp the cover on each side with both hands and pull back to detach.
