Maintenance Manual SP 40
Rev. 005
93
Chapter 5
Test & Diagnostic
RUNNING TEST DISPLAY MESSAGE LEDS PUSHED KEY KEY's ACTION
“KEY 2 (*) (v) (-)“
£
¡
¡
¡
LOAD ON LINE to test
The Key 2
“KEY 3 (-) (v) (*)“
¡
¡
¡
£
ON LINE ON LINE to test
The Key 3
“REPT LOOP SKIP”
£
¥
¡
£
ON LINE
or
STATION 1
or
STATION 2
ON LINE to loop
STATION 1
to repeat the test
STATION 2
to skip the test
Cover Open Test “T&D 08 S_B_S”
l
¡
l
l
ON LINE
or
STATION 1
or
STATION 2
ON LINE to run
STATION 1
to decrement test
STATION 2
to increment test
“OPEN COVER”
¥
£
¡
¥
Raise the front cover
“CLOSE COVER”
¥
£
¡
¥
Close the front cover
“REPT LOOP SKIP”
£
¥
¡
£
ON LINE
or
STATION 1
or
STATION 2
ON LINE to loop
STATION 1
to repeat the test
STATION 2
to skip the test
Printing Adjustment
Test
“T&D 09 S_B_S”
l
¡
l
¡
ON LINE
or
STATION 1
or
STATION 2
ON LINE to run
STATION 1
to decrement test
STATION 2
to increment test
“LOAD PAPER”
¡
¡
£
¡
Load an A4 single
sheet paper.
“LOAD PAPER”
l
¡
l
¡
The adjustment test
is printed
“REPT LOOP SKIP”
£
¥
¡
£
ON LINE
or
STATION 1
or
STATION 2
A buzzer
beep is
sound
ON LINE to loop
STATION 1
to repeat the test
STATION 2
to skip the test
Table 5.3 Step by Step T&D USER Sequential Actions cont'd
