Maintenance Manual SP 40
Rev. 005
94
Chapter 5
Test & Diagnostic
RUNNING TEST DISPLAY MESSAGE LEDS PUSHED KEY KEY's ACTION
Printing Standard
Pattern Module
Test
“T&D 10 S_B_S”
l
¡
¡
l
ON LINE
or
STATION 1
or
STATION 2
A buzzer
beep is
sound
ON LINE to run
STATION 1
to decrement test
STATION 2
to increment test
“LOAD PAPER”
¡
¡
£
¡
Load the same A4
single sheet paper
used in T&D9
“LOAD PAPER”
l
¡
¡
l
The standard pattern
module test is printed
“PAPER OR KEY”
£
¥
¥
£
ANY KEY The standard pattern
module can be
inserted again to
better adjust the
bidirectionality.
Sign with a pen the
line considered the
best one and reload
the single sheet or
press ANY KEY to
skip the test.
“REPT LOOP SKIP”
£
¥
¡
£
ON LINE
or
STATION 1
or
STATION 2
A buzzer
beep is
sound
ON LINE to loop
STATION 1
to repeat the test
STATION 2
to skip the test
Scanner
Adjustment Test
(not used)
“T&D 11 S_B_S”
l
¡
¡
¡
ON LINE
or
STATION 1
or
STATION 2
A buzzer
beep is
sound
ON LINE to run
STATION 1
to decrement test
STATION 2
to increment test
Table 5.3 Step by Step T&D USER Sequential Actions cont'd
