54 • Crestron Zūm® Wired Solutions Product Manual — Doc. 9349B
Controls and Indicators
TEST (1) Pushbutton and (1) green LED;
Push to toggle the switched load output on and off;
Press and hold to cycle the dimming level up and down;
LED indicates that the load is turned on;
LED lights and flashes during room setup and factory reset
ZUMLINK Status (1) bi-color green/red LED;
LED lights green in normal operation;
LED lights red when a fault is detected
Connections
Hot (1) 14AWG Class 1 flying lead;
Black, line power input
Neutral (1) 14AWG Class 1 flying lead;
White, neutral
Red (1) 14AWG Class 1 flying lead, red, AC output
Environmental
Temperature 32° to 104°F (0° to 40°C)
Humidity 10% to 90% RH (noncondensing)
Construction
Housing Plastic, white, UL 94 5VA flame rated
Mounting Mounts to the side of a 4 in. square junction box via a 1/2 in. conduit knockout;
Meets the requirements of UL 2043 for installation in an environmental air-
handling (plenum) space
Dimensions
Height 4.83in. (123mm)
Width 4.25in. (108mm)
Depth 2.03in. (52mm)
Weight
7oz (199g)
Compliance
Regulatory Model: M201933002
cUL916, cUL2043
UL® Listed for US & Canada, IC, FCC Part 15 Class A digital device, UL 916, UL 2043, UL 94 5VA
