CS-Lab CSMIO/IP-A User Manual

4.2 Analog inputs/outputs connector
Axes by default are assigned to following channels: XCh0 / YCh1 / ZCh2 … CCh5. It can be
changed in plugin's configuration.
PIN number
Description
1
Analog output Ch0 (+/-10V)
2
Analog output Ch1 (+/-10V)
3
Analog output Ch2 (+/-10V)
4
Analog output Ch3 (+/-10V)
5
Analog output Ch4 (+/-10V)
6
Analog output Ch5 (+/-10V)
7
Analog output 0 (0-10V)
8
Analog output 1 (0-10V)
9
Analog input 0
10
Analog input 1
11
Analog input 2
12
Analog input 3
13
10V (max. 50mA)
14
GNDCh0
15
GNDCh1
16
GNDCh2
17
GNDCh3
18
GNDCh4
19
GNDCh5
20
GND
21
GND
22
GND
23
GND
24
GND
25
GND
Pay attention to not exceed the
permissable 10V voltage on the analog
inputs. It may cause damage of the de-
vice.
Analog outputs for servo drives (Ch0,
Ch1, Ch2, Ch3, Ch4, Ch5) always connect
with dedicated GND (GND Ch0, GND
Ch1…). Otherwise a servo drive will not
work properly.
Pay attention to not overload 10V volt-
age output. Its permissable load is 50mA.
Connecting the analog signal to a plasma generator you should remember that it should be
galvanically isolated signal.
The connection with use of a simply voltage divider does not protect against surges and may
cause damage of the controller.
There is 50mA max. permissable load on
analog outputs. Exceeding this value may
damage the output circuits.
CS- Lab s.c. – CSMIO/IP- A - CNC controller Page 15
