10.9 Configuration functions in a plug-in window
The configuration window of plugin is activated by „ConfigConfig Plugins” menu position, click
„CONFIG” next to the CSMIO/IP name.
If there were different types of CSMIO/IP controllers installed then click “Config” next to the controller that
will be used.
10.9.1 Axes special functions
Axis configuration is divided into the following groups:
• Servo Alarm Input
• Channels Selection
• Index Homing
• PID Regulator
• Slave Axis Configuration
10.9.1.1 Servo Alarm Input - an alarm input in servo drives
The CSMIO/IP- controller has a possibility of autonomous reaction to fault signals from servo drives. A
drive may generate a fault e.g. in case of overload. If the fault signal appears the CSMIO/IP stops all axis
within 0,1ms. It is worth to configure in servo drives dynamic brake function, which will reduce distance
that an axis move with the power of inertia.
