CS-Lab CSMIO/IP-A User Manual

MoveAxis Group – automatic travel to position:
Pos (mm or inch)
Set motion position
Speed [%]
Motion speed as % of maximal axis speed
Acc [%]
Motion acceleration as % of maximal axis acceleration
Move to set position mode
Move to set position and back to initial position mode
Constant motion mode: to set position, to initial position, to
set position … etc
Start
Start to move
Autotuning –automatic:
Rigidity
Setting target rigidity. By default 50%.
Start
Autotuning mode start
Jog – manual operation:
Feedrate [%]
Motion speed setting
Move towards -
Move towards +
Monitor – axis state preview:
On position
A diode informs that axis does not make any move and is in
set position.
Actual error
Actual deviation value from a set position
(encoder pulses number)
Max error
Maximal temporary error that occurred
(encoder pulses number)
Axis position
Actual axis position (mm or inch)
CS- Lab s.c. – CSMIO/IP- A - CNC controller Page 82
