3 — PROGRAMMABLE PARAMETERS
Table 3 Programmable Parameter Menus: 1313 /1314 Programmer, cont’d
EM BRAKE CONTROL MENU ....... p. 48
—Brake Type
—Pull In Voltage
—Holding Voltage
—Battery Voltage Comp
—Set EM Brake On Fault
—Set Speed Threshold
—Release Delay
—Set Speed Settling Time
—Torque Preload Delay
—Torque Preload Enable
—Torque Preload Cancel Delay
—EM Brake Fault Motor Revs
DRIVERS MENU
—Main Contactor ............... p. 50
—Main Enable
—Main Interlock Type
—Pull In Voltage
—Holding Voltage
—Battery Voltage Comp
—Interlock Type
—Open Delay
—Weld Check Enable
—Main DNC Check Enable
—Main DNC Threshold
—Precharge Enable
—Proportional Driver .......... p. 52
—PD Enable
—Hyd Lower Enable
—PD Max Current
—PD Min Current
—PD Dither %
—PD Dither Period
—PD Kp
—PD Ki
—Driver 3 ........................... p. 53
—Contactor Enable
—Pull In Voltage
—Holding Voltage
—Fault Checking ................. p. 54
—Driver1 Checks Enable
—Driver2 Checks Enable
—Driver3 Checks Enable
—Driver4 Checks Enable
—PD Checks Enable
—External Supply Max
—External Supply Min
—PWM Frequency ............ p. 54
MOTOR MENU ........................... p. 55
—Typical Max Speed
—Control Algorithms .............. p. 55
—Motor Technology
—0-ACIM (Induction Motor)
—Characterization Tests ....p.56
—Test Enable
—Test Throttle
—Motor Poles
—Max Test Speed
—Max Text Current
—SlipGain
—Current Reg ... Enable
—Field Weakening Control .p.57
—FW Base Speed
—Field Weakening Drive
—Weakening Rate Drive
—Min Field Current
—Swap Two Phases . p. 58
—MotorType ................p. 58
—LOS ........................... p. 59
—LOS Upon Encoder Fault
—LOS Max Speed
—LOS Max Current
—LOS Max Mod Depth
—LOS Accel Rate
—LOS Decel Rate
—1-SPM (Surface PM Motor)
—Characterization Tests . p. 60
—Test Enable
—Test Throttle
—Max Test Speed
—Max Test Current
—Feedback Options ............... p. 61
—Feedback Type
—Swap Feedback Direction
—1-Encoder ...................... p. 61
—Encoder Steps
—Encoder Fault Setup ... p. 62
—Fault Detection Enable
—Encoder Pulse Fault Detect
—Fault Stall Time
—2-Sin/Cos ...................... p. 62
—Sin Cos Fault Threshold
—Sin Min
—Sin Max
—Cos Min
—Cos Max
—Temperature Control ........... p. 63
—Sensor Enable
—Sensor Type
—Sensor Offset
—Braking Thermal Cutback Enable
—Temperature Hot
—Temperature Max
—MotorTemp LOS Max Speed
BATTERY MENU
......................... p. 64
—Nominal Voltage
—Kp UV
—Ki UV
—User Overvoltage
—User Undervoltage
—Reset Volts Per Cell
—Full Volts Per Cell
—Empty Volts Per Cell
—Discharge Time
—BDI Reset Percent
DUAL DRIVE MENU .... see Dual Drive
addendum, p/n 53134-DD.
VEHICLE MENU
.......................... p. 67
—Metric Units
—Speed to RPM
—Capture Speed 1
—Capture Speed 2
—Capture Distance 1
—Capture Distance 2
—Capture Distance 3
EMERGENCY REVERSE MENU ..... p. 68
—EMR Enable
—EMR Type
—EMR Dir Interlock
—EMR Time Limit
—EMR Speed
—EMR Accel Rate
—EMR Decel Rate
INTERLOCK BRAKING MENU ....... p. 69
—Enable
—Decel Rate HS
—Decel Rate LS
—Interlock Brake Timeout
