Ports Description
This section describes the device ports and includes the following topics:
• 10/100Base-TX Fast Ethernet Ports
• 1000Base-T Gigabit Ethernet Ports
• 100Base-FX Fiber port
• SFP Port
• DB-9 Console Port
10/100Base-TX Fast Ethernet Ports
The 10/100Base-TX Fast Ethernet ports are RJ-45.
1000Base-T Gigabit Ethernet Ports
The device contains a 1000 Base-TX Gigabit port. The port is an RJ-45 port which supports half- and full-duplex
mode 10/100/1000 Mbps.
100Base-FX Fiber Ports
The 100Base-FX Fast Ethernet port in the DES-3010FA device is a Fiber ports.
SFP Port
Small Form Factor Pluggable (SFP) Optical Transceivers are integrated duplex data GBIC links for bi-directional
communication over multimode optical fiber, designed for high-speed Fiber Channel data links. The SFP port is
designated as 1000Base-X.
The SFP (GBIC) port can be removed and inserted as required. The following figure illustrates the GBIC insertion.
