Device Description
Cable Specifications
Page 15
Cable Specifications
The following table contains the various cable specification for the DES-3010FA/GA:
:
Table 1: DES-3010FA/GA Cable Specifications
Cable Type Description
10Base-TX UTP Category 3, 4, 5 (100 meters max.)
EIA/TIA- 568 150-ohm STP (100 meters max.)
100Base-TX UTP Cat. 5 (100 meters max.)
EIA/TIA-568 150-ohm STP (100 meters max.)
1000Base-T UTP Cat. 5e (100 meters max.)
UTP Cat. 5 (100 meters max.)
EIA/TIA-568B 150-ohm STP (100 meters max.)
1000BASE-LX Single-mode fiber module (10km)
1000BASE-SX Multi-mode fiber module (550m)
1000BASE-LH Single-mode fiber module (40km)
1000BASE-ZX Single-mode fiber module (80km)
Mini-GBIC SFP Transceiver for 1000BASE-LX Single-mode fiber module (10km)
SFP Transceiver for 1000BASE-SX Multi-mode fiber module (550m)
SFP Transceiver for 1000BASE-LH Single-mode fiber module (40km)
SFP Transceiver for 1000BASE-ZX Single-mode fiber module (80km)
Table 2: DES-3010FA/GA Cable Lengths
Cable Type Description
DEM-310GT: SFP Transceiver for 1000BASE-LX, Single-mode fiber module
10km
DEM-311GT: SFP Transceiver for 1000BASE-SX, Multi-mode fiber module 550m
DEM-312GT2: SFP Transceiver for 1000BASE-SX+, Multi-mode module 2km
DEM-314GT: SFP Transceiver for 1000BASE-LH, Single-mode fiber module
50km
DEM-315GT: SFP Transceiver for 1000BASE-ZX, Single-mode fiber module
80km
1000Base-T Category 5e UTP CableCategory 5 UTP Cable(1000 Mbps) 100m
100Base-TX Category 5 UTP Cable (100 Mbps) 100m
10Base-TX Category 3 UTP Cable (10 Mbps) 100m
