DGS-3100 Series Gigabit Stackable Managed Switch User Manual
222
3. Enter a
port ID in the
box a
djacent to the Mask Generate button.
4. Alternatively, click
.
The Generate Mask by range fields appear.
5. Enter a port ID range into the Gene
rate Mask by range fields, and click . The mask is generated.
6. Click
. The ACL profile is added, and the device is updated.
To define L3 IPv6TCP Flag ACL Profile:
This option defines whether or not the TCP Flag field is checked for a match.
1. Click the TCP Flag button
. The ACL Profile L3 Ipv4 TCP Flag Page updates to show the following:
Figure 0-22 ACL Profile L3 IPv6 TCP Flag Page
2. Click
. The ACL profile is added, and the device is updated.
UDP Filtering
If L3 IPv6 ACL UDP is selected, the page updates as follows:
