The number of VLAN interfaces that can be defined for a NetDefendOS installation is limited by
the type of NetDefendOS license. Different hardware models have different licenses and different
limits on VLANs.
Summary of VLAN Setup
Below are the key steps for setting up a VLAN interface.
1. Assign a name to the VLAN interface.
2. Select the physical interface for the VLAN.
3. Assign a VLAN ID that is unique on the physical interface.
4. Optionally specify an IP address for the VLAN.
5. Optionally specify an IP broadcast address for the VLAN.
6. Create the required route(s) for the VLAN in the appropriate routing table.
7. Create rules in the IP rule set to allow traffic through on the VLAN interface.
Note: Port Based VLAN
VLANs on the LAN interfaces of the NetDefend DFL-260E and DFL-860E models are
configured differently from standard NetDefendOS VLANs. The setup is described fully in
Appendix E, DFL-260E/860E Port Based VLAN.
The VLAN processing overhead for these LAN interfaces is performed by the switch
fabric that connects these interfaces and not by NetDefendOS. This allows the interfaces
to be divided up into a number of different VLANs. This feature is referred to as Port
Based VLAN.
It is important to understand that the administrator should treat a VLAN interface just like a
physical interface in that they require both appropriate IP rules and routes to exist in the
NetDefendOS configuration for traffic to flow through them. For example, if no IP rule with a
particular VLAN interface as the source interface is defined allowing traffic to flow then packets
arriving on that interface will be dropped.
VLAN advanced settings
There is a single advanced setting for VLAN:
Unknown VLAN Tags
What to do with VLAN packets tagged with an unknown ID.
Default: DropLog
Example 3.21. Defining a VLAN
This simple example defines a virtual LAN called VLAN10 with a VLAN ID of 10. The IP address of
the VLAN is assumed to be already defined in the address book as the object vlan10_ip.
Chapter 3: Fundamentals
198
