Figure 4.19. Multicast Forwarding - Address Translation
No address translation should be made when forwarding through interface if1. The configuration
of the corresponding IGMP rules can be found below in Section 4.7.3.2, “IGMP Rules Configuration
- Address Translation”.
Tip
As previously noted, remember to add an Allow rule matching the SAT Multiplex rule.
Example 4.18. Multicast Forwarding - Address Translation
The following SAT Multiplex rule needs to be configured to match the scenario described above:
Web Interface
A. Create a custom service for multicast called multicast_service:
1. Go to: Objects > Services > Add > TCP/UDP
2. Now enter:
• Name: multicast_service
• Type: UDP
• Destination: 1234
B. Create an IP rule:
1. Go to: Policies > Firewalling > Main IP Rules > Add > IP Rule
2. Under General enter.
Chapter 4: Routing
367
