10.2. IDP Traffic Shaping
10.2.1. Overview
The IDP Traffic Shaping feature is traffic shaping that is performed based on information coming
from the NetDefendOS Intrusion Detection and Prevention (IDP) subsystem (for more information
on IDP see Section 6.6, “Intrusion Detection and Prevention”).
Application Related Bandwidth Usage
A typical problem that can be solved with IDP Traffic Shaping is dealing with the traffic
management issues caused by bandwidth hungry applications. A typical example of this is traffic
related to peer-to-peer (P2P) data transfer applications which include such things as Bit Torrent
and Direct Connect.
The high traffic loads created by P2P transfers can often have a negative impact on the quality of
service for other network users as bandwidth is quickly absorbed by such applications. An ISP or
a corporate network administrator may therefore need to identify and control the bandwidth
consumed by these applications and IDP Traffic Shaping can provide this ability.
Combining IDP and Traffic Shaping
One of the issues with controlling a traffic type such as P2P is to be able to distinguish it from
other traffic. The signature database of NetDefendOS IDP already provides a highly effective
means to perform this recognition and as an extension to this, NetDefendOS also provides the
ability to apply throttling through the NetDefendOS traffic shaping subsystem when the
targeted traffic is recognized.
IDP Traffic Shaping is a combination of these two features, where traffic flows identified by the
IDP subsystem automatically trigger the setting up of traffic shaping pipes to control those flows.
10.2.2. Setting Up IDP Traffic Shaping
The steps for IDP Traffic Shaping setup are as follows:
1. Define an IDP rule that triggers on targeted traffic.
The IDP signature chosen determines which traffic is to be targeted and the signature
usually has the word "POLICY" in its name which indicates it relates to specific applications
types.
2. Select the rule's action to be the Pipe option.
This specifies that IDP Traffic Shaping is to be performed on the connection that triggers the
rule and on subsequent, related connections.
3. Select a Bandwidth value for the rule.
This is the total bandwidth that will be allowed for the targeted traffic. The traffic measured
is the combination of the flow over the triggering connection plus the flow from any
associated connections, regardless of flow direction.
Connections opened before IDP triggered will not be subject to any restriction.
4. Optionally enter a Time Window in seconds.
Chapter 10: Traffic Management
798
