This example illustrates a multiple ISP scenario which is a common use of policy-based routing.
The following is assumed:
• Each ISP will provide an IPv4 network from its network range. A 2 ISP scenario is assumed in
this case, with the network 10.10.10.0/24 belonging to ISP A and 20.20.20.0/24 belonging to
ISP B. The ISP provided gateways are 10.10.10.1 and 20.20.20.1 respectively.
• All addresses in this scenario are public addresses for the sake of simplicity.
• This is a "drop-in" design, where there are no explicit routing subnets between the ISP
gateways and the NetDefend Firewall.
In a provider-independent network, clients will likely have a single IP address, belonging to one
of the ISPs. In a single-organization scenario, publicly accessible servers will be configured with
two separate IP addresses: one from each ISP. However, this difference does not matter for the
policy routing setup itself.
Note that, for a single organization, Internet connectivity through multiple ISPs is normally best
done with the BGP protocol, which means not worrying about different IP spans or about policy
routing. Unfortunately, this is not always possible, and this is where Policy Based Routing
becomes a necessity.
We will set up the main routing table to use ISP A and add a named routing table called r2 that
uses the default gateway of ISP B.
Interface Network Gateway ProxyARP
lan1 10.10.10.0/24 wan1
lan1 20.20.20.0/24 wan2
wan1 10.10.10.1/32 lan1
wan2 20.20.20.1/32 lan1
wan1 all-nets 10.10.10.1
Contents of the named Policy-based Routing table r2:
Interface Network Gateway
wan2 all-nets 20.20.20.1
The table r2 has its Ordering parameter set to Default, which means that it will only be consulted
if the main routing table lookup matches the default route (all-nets).
Contents of the Policy-based Routing Policy:
Source
Interface
Source
Range
Destination
Interface
Destination
Range
Selected/
Service
Forward
VR table
Return
VR table
lan1 10.10.10.0/24 wan1 all-nets all_services r2 r2
wan2 all-nets lan1 20.20.20.0/24 all_services r2 r2
To configure this example scenario:
Web Interface
1. Add the routes in the list to the main routing table, as shown above.
2. Create a routing table called r2 and make sure the ordering is set to Default.
3. Add the routes found in the list above for the routing table r2.
Chapter 4: Routing
314
