D-Link NetDefendOS

IP Rules
Action Source
Interface
Source
Network
Destination
Interface
Destination
Network
Service MultiplexSAT
Interface
MultiplexSAT If2 If2_net core mc_group mc_stream gre_to_clients
Allow If2 If2_net core mc_group mc_stream
IGMP Rules
Type Action Source
Interface
Source
Network
Multicast
Group
Multicast
Source
Relay
Interface
Query Proxy If2 If2_net mc_group all-nets gre_to_clients
Report Proxy gre_clients all-nets all-nets all-nets If2
B. Client Side Configuration Setup
For the client side configuration, assume the server network is the IPv4 address book object
server_net, the local internal tunnel endpoint is If3_ip (the clients are on the If3 interface). A GRE
tunnel called gre_to_server is configured and the remote network is the address book object
called server_net.
GRE Tunnel
Name IP Address Remote Endpoint Remote Network
gre_to_server If3_ip server_interface_ip server_net
Routes
Provided that the above GRE object has the option to automatically add routes enabled, the
following route will be added by NetDefendOS to the main routing table.
Network Interface
server_net gre_to_server
Services
Name Type Destination Ports
mc_stream udp 1234
IP Rules
Action Source
Interface
Source
Network
Destination
Interface
Destination
Network
Service MultiplexSAT
Interface
MultiplexSAT gre_to_server server_net core mc_group mc_stream If3
Allow gre_to_server server_net core mc_group mc_stream
IGMP Rules
Type Action Source
Interface
Source
Network
Multicast
Group
Multicast
Source
Relay
Interface
Report Proxy If3 If3_net mc_group all-nets gre_to_server
Query Proxy gre_to_server all-nets all-nets all-nets If3
