gw-world:/> add Address IPAddress wwwsrv_priv Address=10.10.10.5
Publish the five public IPv4 addresses on the wan interface using ARP publish. A CLI command
like the following is needed for each IP address:
gw-world:/> add ARP Interface=wan IP=195.55.66.77 mode=Publish
Create a SAT IP rule for the translation:
gw-world:/> add IPRule Action=SAT
Service=http-all
SourceInterface=any
SourceNetwork=all-nets
DestinationInterface=wan
DestinationNetwork=wwwsrv_pub
SATTranslateToIP=wwwsrv_priv
SATTranslate=DestinationIP
SATAllToOne=Yes
Finally, create an associated Allow rule:
gw-world:/> add IPRule Action=Allow
Service=http-all
SourceInterface=any
SourceNetwork=all-nets
DestinationInterface=wan
DestinationNetwork=wwwsrv_pub
Web Interface
Create a SAT IP rule for the translation:
1. Go to: Policies > Firewalling > Main IP Rules > Add > IP Rule
2. Specify a suitable name for the rule, for example SAT_HTTP_To_DMZ
3. Now enter:
• Action: SAT
• Service: http-all
• Source Interface: any
• Source Network: all-nets
• Destination Interface: wan
• Destination Network: wwwsrv_pub
• SAT Translate: Destination IP
• New IP Address: wwwsrv_priv
• Enable the option: All-to-One
4. Click OK
Finally, create an associated Allow rule:
Chapter 7: Address Translation
598
