Description : draft-stenberg-ipsec-nat-traversal-02
VID (Vendor ID)
Payload data length : 16 bytes
Vendor ID : 44 85 15 2d 18 b6 bb cd 0b e8 a8 46 95 79 dd cc
Description : draft-ietf-ipsec-nat-t-ike-00
VID (Vendor ID)
Payload data length : 16 bytes
Vendor ID : cd 60 46 43 35 df 21 f8 7c fd b2 fc 68 b6 a4 48
Description : draft-ietf-ipsec-nat-t-ike-02
VID (Vendor ID)
Payload data length : 16 bytes
Vendor ID : 90 cb 80 91 3e bb 69 6e 08 63 81 b5 ec 42 7b 1f
Description : draft-ietf-ipsec-nat-t-ike-02
VID (Vendor ID)
Payload data length : 16 bytes
Vendor ID : 7d 94 19 a6 53 10 ca 6f 2c 17 9d 92 15 52 9d 56
Description : draft-ietf-ipsec-nat-t-ike-03
Explanation of Values
Exchange type: Main mode or aggressive mode (IKEv1.0 only)
Cookies: A random number to identify the negotiation
Encryption algorithm: Cipher
Key length: Cipher key length
Hash algorithm: Hash
Authentication method: Pre-shared key or certificate
Group description: Diffie Hellman (DH) group
Life type: Seconds or kilobytes
Life duration: No of seconds or kilobytes
VID: The IPsec software vendor plus what standards are supported. For example, NAT-T
Step 2. Server Responds to Client
A typical response from the server is shown below. This must contain a proposal that is identical
to one of the choices from the client list above. If no match was found by the server then a "No
proposal chosen" message will be seen, tunnel setup will fail and the ike -snoop command
output will stop at this point.
Sending IKE packet to 192.168.0.10:500 Exchange type :
Identity Protection (main mode) ISAKMP Version : 1.0
Flags :
Cookies : 0x6098238b67d97ea6 -> 0x5e347cb76e95a
Message ID : 0x00000000
Packet length : 224 bytes
# payloads : 8
Payloads:
SA (Security Association)
Payload data length : 52 bytes
DOI : 1 (IPsec DOI)
Proposal 1/1
Protocol 1/1
Protocol ID : ISAKMP
SPI Size : 0
Transform 1/1
Transform ID : IKE
Encryption algorithm : Rijndael-cbc (aes)
Key length : 128
Hash algorithm : MD5
Authentication method : Pre-Shared Key
Group description : MODP 1024
Life type : Seconds
Life duration : 43200
VID (Vendor ID)
Payload data length : 16 bytes
