User's Manual
19
1) Drag zoom, and focus bar to adjust the video image properly.
2) When the vehicle plate comes into the green line area, click
Snapshot
to take a
snapshot of the plate.
Snapshot
becomes
Resume
.
3) Drag the yellow plate pixel box to the position of the plate.
4) Click
Zoom
.
Zoom in the picture selected by the plate pixel box. It can realize 2x or 4x zoom rate.
5) Adjust the position of plate pixel box, and make it the optimal plate size.
If the plate within the yellow box is larger than the optimal plate size in the example,
zoom out the video image; if smaller, zoom in the video image.
Figure 4-16 Plate pixel size
6) Click
Check Pixel
.
Figure 4-17 Check plate
7) Click
Yes
, and plate pixel configuration is finished.
