User's Manual
54
Parameter Description
Image Size It is in accordance with resolution value.
Quality Set the snapshot quality which includes 6 levels optional.
Picture Coding
Size (KB)
Select picture coding size from 8 options, or select
Custom
to define the
size (50–1024).
You can only select one between picture quality and picture coding size to
set the configuration.
Step 3 Click
Confirm
.
4.5.2.2.3 Interest Area
Set interest area in the image, and then the selected image will display with configured quality.
●
It supports max 3 regions at the same time.
●
The image quality is displayed by level:
Worst, Worse, Bad, Good Better,
or
Best
.
●
Click
Clear
, and delete all the area boxes; Select one box, and then click
Delete
or right-click to
delete it.
Step 1 Select
Setting
>
Camera
>
Video
>
Interest Area
.
Figure 4-61 Interest area
Step 2 Configure parameters.
Table 4-29 Interest area parameter description
Parameter Description
Image Quality Set snapshot quality, which includes 6 levels optional.
