User's Manual
5
Table 2-1 Camera structure description
No. Description No. Description
1 Protective cover 3 Lens
2 Illuminator —
2.3.2 Rear Panel
Figure 2-7 Rear panel structure
Table 2-2 Description of rear panel structure
No. Description No. Description
1 Debugging port 3 Hardware reset
2 TF card —
2.4 Cable Connection
Two cable connection methods are available, and might differ from the actual product.
Figure 2-8 Cable connection (1)
