User's Manual
20
Figure 4-18 Recognition
Step 4 Configure recognition area.
The configuration example on the right of video page can be used as a reference.
1) Click
Iden Area
(identification area).
Click, and draw 4 lines on the video page, and the recognition area is formed.
2) Click
Snap Line
.
Draw snap line by dragging mouse on the area. The snap line must cross the area.
3) Click
Save
to complete the Settings.
Step 5 Click
Finish
, exit
Guide
page, and enter
Live
page.
4.3 Live
Click the
Live
tab.
On this page, it can realize several functions such as live video, live picture, real-time capture, record,
and config (LPR), and more.
Figure 4-19 Live
Table 4-4 Live page bar
No. Description No. Description
1 Video stream 5 System functions
2 Live view 6 Functions of Live page
3 Logged plate number 7 Vehicle snapshot
4 Plate snapshot 8 Event list
