User's Manual
51
Parameter Description
Mode
Select the way of adjusting exposure mode. You can select from
Manual
, and
Auto
.
Shutter
You need to set shutter when set
Mode
to
Manual
.
Shutter Scope
Set the time range of shutter.
You need to set shutter when
Customized Range
is set as
Shutter
.
Gain Scope
Set the value range of gain.
You need to set gain scope when set
Mode
to
Manual
.
WB
Mode Set scene mode to adjust the image to its best status.
Step 3 Click
Save
.
4.5.2.1.3 Metering Zone
This section provides guidance on setting the measure mode of metering zone.
Step 1 Select
Setting
>
Camera
>
Attribute
>
Metering Zone
.
Figure 4-58 Metering Zone
Step 2 Configure parameters.
Table 4-26 Metering zone parameter description
Parameter Description
Plate Light
When selecting
Enable
, you can turn
ON
or
OFF
backlight, and frontlight
according to scene requirement, and then improve the backlight image
brightness.
Backlight
Frontlight
