User's Manual
52
Parameter Description
Measure Mode
Global Measure
: Measure the brightness of the whole image area, and
intelligently adjust the overall image brightness.
Partial Measure
: Measure the brightness of sensitive area, and
intelligently adjust the overall image brightness. If the measured area
becomes bright, then the whole area becomes dark, and vice versa.
Drag to select the measured area, and the system displays yellow box. Drag
the box to proper location, and then click
Confirm
to complete configuration.
Step 3 Click
Confirm
.
4.5.2.2 Video
4.5.2.2.1 Video
You can set the camera stream information.
Step 1 Select
Setting
>
Camera
>
Video
>
Video
.
Figure 4-59 Video
Step 2 Configure parameters.
Table 4-27 Video parameters description
Parameter Description
Main Stream
Stream Type Currently it supports normal stream.
Encode Mode
Currently it only supports H.264B, H.264M, H.264H,
H.265, and MJPEG.
Resolution
Select the resolution of the video.
The resolution of sub stream cannot be greater than
main stream.
Frame Rate(FPS) Select frame rate as needed.
Bit Rate Type
Include VBR, and CBR.
Image quality can only be set in VBR mode.
