Local Configurations 82
If the backup is successful, the system pops up a message indicating the backup is
completed.
Click Save.
Step 4
4.3.3.2 Configuring 3G/4G Network Settings
You can connect the Device to the Internet through 3G/4G network or Wi-Fi. Make sure the
Device can communicate with other devices in the network diagram. The Device can also work
as a hotspot to share the network connection to other terminals.
If both 3G/4G and Wi-Fi are available, the Device connects to Wi-Fi and disconnected from
3G/4G.
4.3.3.2.1 Configuring 3G/4G Settings
Connect the Device to 3G/4G network through dial-up method of different Operator, and then
you can receive the information such as alarm information, audio and video, image, and device
status.
Preparation
Make sure the Device is equipped with 3G/4G module and inserted with SIM card from the
Communication Operator.
The dial number, user name, and password have been obtained from the Communication
Operator.
Procedure
Select Main Menu > VEHICLE > 3G/4G. Step 1
The 3G/4G interface is displayed. See Figure 4-67.
The 3G/4G interface is consisted of three areas:
Area 1: Displays signal strength, which displays only when 3G/4G is enabled.
Area 2: Displays 3G/4G module configuration information, which is available only
when 3G/4G module is connected.
Area 3: Displays 3G/4G module state information, which is available only when
3G/4G function is enabled.
The Device supports upgrading some firmwares of 4G module. Click firmware update
to update 4G module firmwares.
