Instruction SiEN18-622
214 System Configuration
FTK(X)S 50/60/71 F(B), FTXS 50/60/71 D
You can adjust the air flow direction to increase your comfort.
To adjust the horizontal blade (flap)
1. Press “SWING button ”.
• “ ” is displayed on the LCD and the
flaps will begin to swing.
2. When the flap has reached the desired
position, press “SWING button ”
once more.
• The flap will stop moving.
• “ ”disappears from the LCD
To adjust the vertical blades (louvers)
3. Press “SWING button ”.
• “ ” is displayed on the LCD.
4. When the louvers have reached the desired position,
press the “SWING button ” once more.
• The louvers will stop moving.
• “ ” disappears from the LCD.
TIMER
ON
CANCEL
OFF
1, 2
3, 4
To Next Page
