Table 65: iC2-Micro Frequency Converters- Mains: 3x200–240VAC, 40% Duty Cycle
Power
rating
P
m (HO)
R
min
R
br. nom
R
rec
P
br avg
Code
number
Period Cable cross-
section
(1)
Thermal
relay
Maximum
brake
torque
with
resistor
3-phase
200–
240 V
[kW
(hp)]
[Ω] [Ω] [Ω] [kW (hp)] 175Uxxxx [s]
[mm
2
(AWG)]
[A] [%]
07A8 1.5 (2.0) 53 62.70 59 0.541 (0.725) 3302 120 1.5 (16) 2.7 143
11A0 2.2 (3.0) 35 42.06 39 0.807 (1.082) 3303 120 1.5 (16) 4.2 140
15A2 3.7 (5.0) 20 24.47 23 1.386 (1.859) 3305 120 1.5 (16) 6.8 145
24A2 5.5 (7.5) 14 17.28 16 2.070 (2.776) 3306 120 1.5 (16) 10.4 144
31A0 7.5 (10) 9 12.56 11 2.847 (3.818) 3307 120 2.5 (14) 14.7 145
46A2 11 (15) 7 8.49 8 4.215 (5.652) 3176 120 4 (12) 23 141
1) All cabling must comply with national and local regulations on cable cross-sections and ambient temperature.
