8 How to Order
8.1 Model Code
The configuration of the drive is reflected in the model code. The model code can be used to identify the specific drive configuration and
its inbuilt features.
e30bv086.10
1
2
3
4
5
6
7
8
9
10
11 12
13 14 15 16 17 18 19 20 21 22 23 24 25 26 27
i
C
2
-
3
0
F
A
3
1
N
N
0 4
0 2
- 0 1 A 2 E 2 0 F 0
F 2
F 4
+ A C B C
A C X X
Figure 59: Model Code
Table 59: Example of a Final Model Code
Description Position Function
Product group 1–6 iC2-30
Product category 7–8 FA: Frequency converter, air-cooled
Product type 9–10 • 3N: 3-phase power supply
• 1N: 1-phase power supply
Mains voltage 11–12 • 01: 100–120 V AC
• 02: 200–240VAC
• 04: 380–480VAC
Current rating 14–17 01A2–46A2
Protection rating 18–20 E20: IP20/Open Type
EMC category 21–22 • F0: C1 category (with integrated EMC filter)
• F2: C2 category (with integrated EMC filter)
• F4: C4 category (without integrated EMC filter)
Integrated brake chopper Plus code • +ACBC: With integrated brake chopper
• +ACXX: Without integrated brake chopper
8.2 Ordering Accessories and Spare Parts
Table 60: Code Numbers for Ordering Accessories
Category Part name Code number
IP21/Type 1 conversion kit, MA01c 132G0188
IP21/Type 1 conversion kit, MA02c 132G0189
IP21/Type 1 conversion kit, MA01a 132G0190
IP21/Type 1 conversion kit, MA02a 132G0191
IP21/Type 1 conversion kits
IP21/Type 1 conversion kit, MA03a 132G0192
