Design Guide | iC2-Micro Frequency Converters Specifications
4.2.7.3 Ambient Conditions during Transport
Table 30: Ambient Conditions during Transport
Function Data
Ambient temperature -25°...+70°C (-13°...+158°F)
Climatic condition 2K11, maximum 95% non-condensing
Chemically active substances 2C2
Solid particles (non-conductive particles or dust only) 2S5
Vibration 2M5
Shock 2M4
Biological ambient 2B1
4.2.7.4 Ambient Conditions during Operation
Table 31: Ambient Conditions during Operation
Function Data
Ambient temperature -20 °C to 55 °C (-4 °F to 131 °F), and -10 °C to 50 °C (14 °F to 131 °F)
without derating
Climatic condition 3K22, maximum 95% non-condensing
(1)
Chemically active substances C4
Solid particles (non-conductive particles/dust) 3S6
Vibration 3M11
Shock 3M11
Biological ambient 3B1
Without derating: 1000m (3280 ft)
With derating: 1000 m (3280 ft) to 4000 m (13123 ft), derate the
output current by 1% for each 100 m (328 ft).
Maximum altitude above sea level
Regarding IEC 61800-5-1 compliance, the default maximum alti-
tude is 2000m (6562ft). When the installation site is at an altitude
of 2000m (6562 ft) to 4000 m (13123 ft), contact Danfoss for fur-
ther information.
1) Ensure maximum rate of change of temperature 0.1°C/min (0.18°F/min) to avoid condensation.
4.3 Fuses and Circuit Breakers
For proper protection of the installation cable and the drive, fuses and/or circuit breakers must be used. If short circuit occurs, fuses and
circuit breakers protect the power cable and limit the damage to the drive and components connected to the drive.
When using circuit breakers, be aware of the limitation to the short-circuit capacity of the supply, and follow the installation instructions
from the manufacturer. The short-circuit rating must comply with the values given in Table 32.
Danfoss A/S © 2024.08 AJ402315027937en-000401 / 130R1239 | 45
