Design Guide | iC2-Micro Frequency Converters How to Order
Table 63: iC2-Micro Frequency Converters- Mains: 3x200–240VAC, 10% Duty Cycle
Power
rating
P
m (HO)
R
min
R
br. nom
R
rec
P
br avg
Code
number
Period Cable cross-
section
(1)
Thermal
relay
Maximum
brake
torque
with
resistor
3-phase
200–
240 V
[kW
(hp)]
[Ω] [Ω] [Ω] [kW (hp)] 175Uxxxx [s]
[mm
2
(AWG)]
[A] [%]
07A8 1.5 (2.0) 53 62.70 59 0.128 (0.172) 3026 120 1.5 (16) 1.6 143
11A0 2.2 (3.0) 35 42.06 39 0.190 (0.225) 3031 120 1.5 (16) 1.9 140
15A2 3.7 (5.0) 20 24.47 23 0.327 (0.439) 3326 120 1.5 (16) 3.5 145
24A2 5.5 (7.5) 14 17.28 16 0.463 (0.621) 3327 120 1.5 (16) 5.3 144
31A0 7.5 (10) 9 12.56 11 0.636 (0.853) 3328 120 1.5 (16) 6.8 145
46A2 11 (15) 7 8.49 8 0.942 (1.263) 3329 120 2.5 (14) 10.5 141
1) All cabling must comply with national and local regulations on cable cross-sections and ambient temperature.
8.3.3 Ordering Brake Resistors 40%
Table 64: iC2-Micro Frequency Converters - Mains: 3x380–480VAC, 40% Duty Cycle
Power
rating
P
m (HO)
R
min
R
br. nom
R
rec
P
br avg
Code
number
Period Cable cross-
section
(1)
Thermal
relay
Maximum
brake
torque
with
resistor
3-phase
380–
480 V
(T4)
[kW
(hp)]
[Ω] [Ω] [Ω] [kW (hp)] 175Uxxxx [s]
[mm
2
(AWG)]
[A] [%]
05A3 2.2 (3.0) 139 163.95 155 0.807 (1.082) 3312 120 1.5 (16) 2.1 131
07A2 3 (4.0) 100 118.86 112 1.113 (1.491) 3313 120 1.5 (16) 2.7 131
09A0 4 (5.0) 74 87.93 83 1.504 (2.016) 3314 120 1.5 (16) 3.7 128
12A0 5.5 (7.5) 54 63.33 60 2.088 (2.799) 3315 120 1.5 (16) 5 127
15A5 7.5 (10) 38 46.05 43 2.872 (3.850) 3316 120 1.5 (16) 7.1 132
23A0 11 (15) 27 32.99 31 4.226 (5.665) 3236 120 2.5 (14) 11.5 130
31A0 15 (20) 19 24.02 22 5.804 (7.780) 3237 120 2.5 (14) 14.7 129
37A0 18.5
(25)
16 19.36 18 7.201 (9.653) 3238 120 4 (12) 19 132
43A0 22 (30) 16 18.00 17 8.604 (11.534) 3203 120 4 (12) 23 128
1) All cabling must comply with national and local regulations on cable cross-sections and ambient temperature.
Danfoss A/S © 2024.08 AJ402315027937en-000401 / 130R1239 | 101
