4 Specifications
4.1 Electrical Data
4.1.1 Mains Supply 1x100–120 V AC
Table 14: Mains Supply 1x100–120 V AC
Normal overload 150% for 1 minute
Frequency converter 02A4 04A8
Typical shaft output [kW] 0.37 1.1
Typical shaft output [hp] 0.5 1.5
Enclosure size MA01c MA02c
Output current
Continuous (3x200–240 V AC) [A] 2.4 4.8
Intermittent (3x200–240 V AC) [A] 3.6 7.2
Maximum cable size
(Mains, motor) [mm
2
/AWG] 4/10
Maximum input current
Continuous (1x100–120 V) [A] 11.6 25.6
Intermittent (1x100–120 V) [A] 17.4 38.4
EMC filter type C4
Environment
Power loss [W]
(1)(1)
18 24
Efficiency [%]
(1)
97.4 98.2
1) The value is measured at 100% rated torque-producing current and 90% rated motor stator frequency according to IEC 61800-9-2 and EN 50598-2.
4.1.2 Mains Supply 1x200–240 V AC
Table 15: Mains Supply 1x200–240 V AC
Normal overload 150% for 1 minute
Frequency converter 02A2 04A2 06A8 09A6
Typical shaft output [kW] 0.37 0.75 1.5 2.2
Typical shaft output [hp] 0.5 1.0 2.0 3.0
Enclosure size MA01c MA01c MA02c MA02a
Output current
Continuous (3x200–240 V AC) [A] 2.2 4.2 6.8 9.6
Intermittent (3x200–240 V AC) [A] 3.3 6.3 10.2 14.4
