Design Guide | iC2-Micro Frequency Converters Specifications
Table 15: Mains Supply 1x200–240 V AC (continued)
Maximum cable size
(Mains, motor) [mm
2
/AWG] 4/10
Maximum input current
Continuous (1x200–240 V) [A] 6.1 11.6 18.7 26.4
Intermittent (1x200–240 V) [A] 8.3 15.6 26.4 37
EMC filter type C1/C4
Environment
Power loss [W]
(1)(1)
16 31 46 61
Efficiency [%]
(1)
97.5 97.6 97.6 97.9
1) The value is measured at 100% rated torque-producing current and 90% rated motor stator frequency according to IEC 61800-9-2 and EN 50598-2.
4.1.3 Mains Supply 3x200–240 V AC
Table 16: Mains Supply 3x200–240 V AC
Normal overload 150% for 1 minute
Frequency converter 02A4 04A2 07A8 11A0 15A2 24A2 31A0 46A2
Typical shaft output [kW] 0.37 0.75 1.5 2.2 3.7 5.5 7.5 11
Typical shaft output [hp] 0.5 1.0 2.0 3.0 5.0 7.5 10 15
Enclosure size MA01a MA01a MA02a MA03a MA03a MA04a MA04a MA05a
Output current
Continuous (3x200–240 V AC) [A] 2.4 4.2 7.8 11 15.2 24.2 31 46.2
Intermittent (3x200–240 V AC) [A] 3.6 6.3 11.7 16.5 22.8 36.3 46.5 69.3
Maximum cable size
(Mains, motor) [mm
2
/AWG] 4/10 16/6
Maximum input current
Continuous (3x200–240 V) [A] 3.8 6.7 12.5 17.7 24.3 33.0 42.0 42.0
Intermittent (3x200–240 V) [A] 5.7 8.3 18.8 26.6 35.3 49.5 63.0 63.0
EMC filter type C4
Environment
Power loss [W]
(1)(1)
21 36 53 80 92 162 228 385
Efficiency [%]
(1)
97.3 97.4 97.9 97.7 97.5 97.7 97.6 97.3
1) The value is measured at 100% rated torque-producing current and 90% rated motor stator frequency according to IEC 61800-9-2 and EN 50598-2.
