Design Guide | iC2-Micro Frequency Converters Electrical Installation Considerations
Table 55: Terminal Descriptions (continued)
Terminal Parameter Default setting Description
Parameter P 9.4.1.4 Terminal 15
Digital Input
[1] Reset
Parameter P 9.4.2.2 Terminal 15
Digital Output
[0] No Operation
15
Parameter P 9.4.5.1 Terminal 15
Pulse Output
[0] No Operation
Selectable for either digital input, digital output, or pulse
output. The default setting is digital input.
17 Parameter P 9.4.1.5 Terminal 17
Digital Input
[14] Jog Digital input.
18 Parameter P 9.4.1.6 Terminal 18
Digital Input
[0] No Operation Digital input, can also be used for pulse input.
20 Common for digital and analog inputs.
Analog inputs/outputs
31 Parameter P 9.5.1.1 Terminal 31
Mode
[0] 0–20 mA Programmable analog output. The analog signal is 0–
20mA or 4–20mA at a maximum of 500Ω.
32 +10VDC 10VDC analog supply voltage. 25mA maximum com-
monly used for potentiometer or thermistor.
33 Parameter P 9.5.2.1 Terminal 33
Mode
[1] Voltage Mode Analog input. Selectable between voltage or current
mode.
34 Parameter P 9.5.3.1 Terminal 34
Mode
[1] Voltage Mode Analog input. Selectable between voltage or current
mode.
35 Common for digital and analog inputs.
Serial communication
61 Common for RS485 interface.
68 (+) Parameter group G 10.1 FC Port
Settings
69 (-) Parameter group G 10.1 FC Port
Settings
RS485 interface. A switch is provided for termination resis-
tance.
Relays
01, 02,
03
Parameter P 9.4.3.1 Function
Relay
[9] Fault Form C relay output. These relays are in various locations
depending on the drive configuration and size. Usable for
AC or DC voltage and resistive or inductive loads.
7.10.5 Control Wire Sizes and Stripping Lengths
Connections are made by pushing solid wire into the connector. If flexible (multicore) wire is used, ferrules are recommended. When
flexible wire is used without ferrules, the connector is pushed with a small screwdriver as shown in Figure 50. The maximum size of the
screwdriver is 3mm.
Danfoss A/S © 2024.08 AJ402315027937en-000401 / 130R1239 | 93
