Danfoss iC2-Micro Series - Relay Output; Auxiliary Voltages

Design Guide | iC2-Micro Frequency Converters Specifications
Table 25: Analog Output
Function Data
Terminal number T31
Output range: Current 0/4–20mA
Maximum load resistor to GND 500Ω
Resolution 0.1% of full scale
Accuracy 1% of full scale
4.2.5.6 Relay Output
Relays provide PELV isolation to supply voltage, other high-voltage terminals and low-voltage control.
Table 26: Relay Output
Function Data
Terminal number 01, 02, and 03
Relay configuration SPDT (NO/NC)
Maximum terminal load (AC-1): Resistive load 250VAC, 2A
Maximum terminal load (AC-15): Inductive load @ cosφ=0.4 250VAC, 0.2A
Maximum terminal load (DC-1): Resistive load 30VDC, 2A
Maximum terminal load (DC-13): Inductive load 24VDC, 0.1A
Minimum load • 24VDC, 10mA
• 24VAC, 20mA
4.2.5.7 Auxiliary Voltages
Auxiliary voltage outputs are used as reference for analog and digital inputs.
Table 27: Auxiliary Voltages
Function Data
Output voltage +10.5V ±0.5V10V output
Maximum load 25mA
Output voltage +24V ±20%24V output
Maximum load 100mA
Danfoss A/S © 2024.08 AJ402315027937en-000401 / 130R1239 | 43
