Table 19: Mains Supply (continued)
Function Data
Displacement power factor near unity (>0.98)
MA01a–MA03a: Maximum 2 times/minSwitching on input supply from a dis-
charged drive
MA04a–MA05a: Maximum 1 time/min
Environment Overvoltage category III/pollution degree 2
4.2.3 Motor Output and Motor Data
Table 20: Motor Output (U, V, W)
Function Data
Output voltage 0–100% of supply voltage
Output frequency
(1)
Induction motor
• 0–200Hz (VVC+ mode)
• 0–500Hz (U/f mode)
PM motor
• 0–400Hz (VVC+ mode)
Frequency resolution 0.001Hz
Switching on output ±0.003Hz
1) Dependent on voltage, current, and control mode.
4.2.4 Torque Characteristics
Table 21: Torque Characteristics
Function Data
Overload torque 150% for 60 s every 10 min
Overload torque at start 200% for 1 s
Torque rise time (VVC+) 50 ms
4.2.5 Control I/O
4.2.5.1 Control I/O Overview
This chapter covers the general specifications of the control I/O.
The standard configuration for iC2-Micro Frequency Converters is:
l 4 digital inputs.
l 1 digital I/O (Select ether digital input or output).
l 2 analog inputs (voltage or current).
l 1 analog output (current).
l 1 relay outputs (NC/NO).
l 24V and 10V reference for digital and analog I/O.
