Danfoss iC2-Micro Series - Analog Input; Analog Output

Table 23: Digital and Pulse Output
Function Data
Terminal number T15
(1)
Voltage level 0/24V
Maximum output load (sink/source) 40mA
Frequency range - Pulse output 4Hz–32kHz
Maximum load 1kΩ
Maximum capacitive load at maximum
frequency
10nF
Pulse output accuracy 0.1% of full scale
Digital output (24V)
Resolution of pulse output 10bit
1) T15 is selectable for either digital input, digital output, or pulse output. The default setting is digital input.
4.2.5.4 Analog Input
Control inputs and outputs are PELV galvanically isolated from supply voltage and other high-voltage terminals, unless otherwise
specified.
Table 24: Analog Input
Function Data
Terminal number T33 and T34
Input mode Current or Voltage
(1)
Voltage mode • Voltage range: 0–10V (scalable)
• Input impedance: 10kΩ
• Maximum voltage: +20V/-12V
Current mode • Current range: 0/4-20mA (scalable)
• Input impedance: 200Ω
• Maximum current: 30mA
Resolution 0.1% of full scale
Accuracy 1% of full scale
Bandwidth 100Hz
1) The selection is made in the software. For more information, refer to the application guide.
4.2.5.5 Analog Output
Control inputs and outputs are PELV galvanically isolated from supply voltage and other high-voltage terminals, unless otherwise
specified.
