Table 39: dU/dt Data for iC2-Micro Frequency Converters (continued)
Enclosure size Power [kW(hp)] Cable length
[m(ft)]
Mains voltage
[V]
Rise time [μ
sec
] U
PEAK
[kV] dU/dt [kV/μ
sec
]
MA02c 1.1 (1.5) 5 (16.4) 1x120 0.132 0.464 2.82
MA02c 1.1 (1.5) 50 (164) 1x120 0.31 0.622 1.62
MA02c 1.5 (2.0) 5 (16.4) 1x240 0.132 0.464 2.82
MA02c 1.5 (2.0) 50 (164) 1x240 0.31 0.622 1.62
MA01a 0.75 (1.0) 5 (16.4) 3x240 0.092 0.458 3.96
MA01a 0.75 (1.0) 50 (164) 3x240 0.296 0.616 1.66
MA01a 1.5 (2.0) 5 (16.4) 3x400 0.132 0.732 4.46
MA01a 1.5 (2.0) 50 (164) 3x400 0.389 1.056 2.18
MA01a 1.5 (2.0) 5 (16.4) 3x480 0.143 0.848 4.76
MA01a 1.5 (2.0) 50 (164) 3x480 0.417 1.232 2.36
MA02a 1.5 (2.0) 5 (16.4) 3x240 0.09 0.52 4.69
MA02a 1.5 (2.0) 50 (164) 3x240 0.23 0.56 1.95
MA02a 2.2 (3.0) 5 (16.4) 1x240 0.078 0.562 5.71
MA02a 2.2 (3.0) 50 (164) 1x240 0.214 0.614 2.29
MA02a 4.0 (5.5) 5 (16.4) 3x400 0.136 0.752 4.47
MA02a 4.0 (5.5) 50 (164) 3x400 0.254 1.048 3.30
MA02a 4.0 (5.5) 5 (16.4) 3x480 0.149 0.896 4.85
MA02a 4.0 (5.5) 50 (164) 3x480 0.305 1.232 3.23
MA03a 3.7 (5.0) 5 (16.4) 3x240 0.078 0.529 5.46
MA03a 3.7 (5.0) 50 (164) 3x240 0.228 0.636 2.23
MA03a 7.5 (10) 5 (16.4) 3x400 0.098 0.804 6.08
MA03a 7.5 (10) 50 (164) 3x400 0.288 1.02 2.83
MA03a 7.5 (10) 5 (16.4) 3x480 0.112 0.926 6.02
MA03a 7.5 (10) 50 (164) 3x480 0.304 1.22 3.23
MA04a 7.5 (10) 5 (16.4) 3x240 0.116 0.5 3.47
MA04a 7.5 (10) 50 (164) 3x240 0.288 0.574 1.60
MA04a 15 (20) 5 (16.4) 3x400 0.144 0.71 3.96
MA04a 15 (20) 50 (164) 3x400 0.28 1.0 2.88
MA04a 15 (20) 5 (16.4) 3x480 0.172 0.794 3.71
MA04a 15 (20) 50 (164) 3x480 0.298 1.19 3.20
MA05a 11 (15) 5 (16.4) 3x240 0.078 0.407 4.14
MA05a 11 (15) 50 (164) 3x240 0.492 0.59 0.96
