19. In the tree menu under Modify Settings, select Network | Settings. The Network
Settings window opens.
20. Adjust the parameters for each head as shown in the table below. Click Update to
save the parameters.
Dimensioner Name
HEAD1
HEAD2
IP Address 1
192.168.3.101
192.168.3.102
Net Mask 1
255.255.255.0
255.255.255.0
Data Transmit IP Address
192.168.3.70
192.168.3.70
Data Transmit Port
10001
10002
Tach Master Checkbox (Tach
sync source)
HEAD1 is always the
master, and this selection
is found in Modify
Settings |
Tach/Trigger/Transmit.
