DC3000 USER INTERFACE
87
4
Field Name
Action/Definition
Dimensions
Format
Select in what order you would like the Length, Width, and Height
measurements to appear in the message. L=Length / W=Width / H=Height
Field Width
Select the field width of the minimal number of characters for length, width,
and height from the drop-down list. 2 to 7 characters are available. If the
value has fewer characters than the field width, it will be padded with zeros
on the left.
For example:
If Precision is set at 1 (1 decimal place), field width is set at 5, and the
dimension is 12.3, then the returned value in the host message will be
012.3
If Precision is set at 2 (2 decimal place), field width is set at 7, and the
dimension is 12.3, then the returned value in the host message will be
0012.30
Dimension
Units
Select in (inches), mm (millimeters), or cm (centimeters) from the drop down
list.
Precision
Select 0, 1, or 2 from the drop-down list. This is the number of digits
appearing after the decimal point.
Field Delimiter
Enter a character to be used as a delimiter between length, width, and height
fields. A semicolon is often used to separate data.
Omit Decimal
Select this check box to remove the decimal point character from the
message. Only the decimal point character is removed, and digits before and
after the decimal point remain.
Lead Padding
Enter characters to proceed the length, width, and height field.
Trail Padding
Enter characters to follow the length, width, and height field.
Append Units
Select the check box to enable. When checked, a Separator text field is
revealed. Enter a separator character in the text field provided. A unit
abbreviation (mm, cm, or in) will be appended after the separator.
Append Ready
Status
Select the check box to enable. When checked, a Separator text field is
revealed. Enter a separator character in the text field provided. NOTREADY
or READY will be appended after the separator. NOTREADY indicates that
this package result is not legal-for-trade.
Append
NoDim
Status
Select the check box to enable. When checked, a Separator text field is
revealed. Enter a separator character in the text field provided. If the
package is a NoDim, a reason code is appended after the separator.
For example: NODIM_BOX_STACKED, NODIM_BOX_SIDES_TO_NOISY
A NoDim reason indicates that this package result is not legal-for-trade.
