5. Scan the END bar code once to finish the string, then scan END again to
exit Programming Mode.
NOTE
If all 20 characters will be used in the prefix or suffix, do not scan the END bar
code to finish
the string. It is done automatically.
6. The resulting message string would appear as follows:
Scanned bar code data:12345
Resulting message string output: $12345
Label ID
A Label ID is used to identify a bar code (symbology) type. See Appendix D,
Factory Default Se
ttings, for a listing for common symbologies. It can be
appended previous to or following the
transmitted bar code data depending
upon how this option is enabled. This feature provides options for configuring
custom Label IDs individually per symbology. If you wish to program the scan-
ner to always include an industry standard label
identifier for ALL symbology
types, see the feature, AIM ID on page 2-75.
The Label ID is a customizable code of up to
three ASCII characters (each of
which are 00-7F) followed by a control character (00-01), This control charac-
ter, when set to zero, does nothing. Wh
en set to one, it appends the symbol-
ogy’s AIM ID to the Label ID.
NOTE
When the control character is set to 01 for UPC-A and UPC-E, it expands the
label to EAN-13 and thus follows the EAN-13 Label ID settings.
To configure a Label ID:
1. Scan the Enter/Exit Programming
Mode bar code.
2. Select Label ID position
as either BEFORE or AFTER by scanning the appro-
priate bar code.
3. Scan a bar code to select the symbology for which you wish to configure a
cu
stom Label ID.
4. Determine the desired character(s) (you may choose up to three) which will
re
present the Label ID for the selected symbology. Next, turn to the ASCII
Character Set on page i on the inside back cover o
f this manual and find
the equivalent hex digits associated with your choice of Label ID. For
ex
ample, if you wish to select an equal sign (=) as a Label ID, the chart
indicates its associated hex characters as 3D.
5. Turn to Appendix C, and scan the bar codes repr
esenting the hex charac-
ters determined in the previous step. For example, to make an equal sign
(=), scan
‘3’ and ‘D’ followed by ‘0’ six times. Since this is a three-charac-
ter buffer, ‘00’ is scanned for characte
r two, ‘00’ for character three and
‘00’ for the control character. (‘00’ indicates no character.)
6. Scan the END bar code to exit programming mode.

Datalogic MAGELLAN 3200VSI Specifications

General

Tilt angle range	0 - 360 °
Decoding standards	1D/2D/GS1/PDF417
Dimensions (WxDxH)	142 x 152 x 82 mm
Power consumption (standby)	1.8 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Cable length	4.5 m
Standard interfaces	USB
Certification	RoHS

Weight and Dimensions

Weight	600 g
