Appendix E
Keyboard Function Key Mappings
Keyboard Model Cross Reference
Table 2 summarizes the keyboard models, their defined protocol, scancode set,
and some unique features. The remaining t
ables in this chapter provide the
function key maps associated with each of the scancode sets.
Table 2. Keyboard Model Cross Reference
Model Type I/F ID
Transmission
Protocol
Scancod
e
Set
Func.
Key
Map
Suppo
rt
Use
Country
Mode
PC/XT Foreign ALT Mode
Wedge A PC/XT Scan Set 1 No No
AT; 
PS/2 25-286; 
PS/2 30-286; 
PS/2 50, 50Z; 
PS/2 60,70,80,90,95 
Foreign ALT Mode
Wedge B AT/PS2 Scan Set 2 No No
PS/2 25 and 30 
Foreign ALT Mode
Wedge C AT/PS2 Scan Set 1 No No
PC/XT U.S. Mode
Wedge D PC/XT Scan Set 1 Yes No
AT; 
PS/2 25-286; 
PS/2 30-286; 
PS/2 50, 50Z; 
PS/2 60,70,80,90,95 
U.S. Mode + specific 
country support
Wedge E AT/PS2 Scan Set 2 Yes Yes
PS/2 25 and 30 
U.S. Mode
Wedge F AT/PS2 Scan Set 1 Yes No
IBM 3xxx Terminals 
(122-key keyboard)
Wedge G AT/PS2 Scan Set 3 Yes No
IBM 3xxx Terminals 
(102-key keyboard)
Wedge H AT/PS2 Scan Set 3 Yes No
PS55 5530T with 
JAPANESE DOS (TDOS)
Wedge I AT/PS2
Japanese
DOS
Yes No
NEC 9801
Wedge J
NEC
98
01
NEC 9801 Yes No
