2D Global Features Enter/Exit Programming Mode
Product Reference Guide
187
Data Matrix Set Length 2
This feature specifies one of the bar code lengths for Data Matrix Length
Control. Length 2 is the maximum label length if in Variable Length Mode,
or the second fixed length if in Fixed Length Mode. Characters can
be set
from 0001 to 3,116 characters in increments of 0001 (pad with zeroes).
See page 290 for detailed instructions on setting this feature.
Select Data Matrix Length 2 Setting
To configure this feature, scan the ENTER/EXIT
PROGRAMMING MODE bar code above, then the bar
code at left followed by the digits from the Alphanu-
meric characters in
Appendix D, Keypad
repre-
senting your desired character(s). End by scanning
the ENTER
/EXIT bar code again.
Make a mistake? Scan the CANCEL bar code to abort
and not
save the entry string. You can then start
again at the beginning.
CANCEL
Length 2 is 3,116 Characters
To Next Page
