Datalogic PowerScan PD9531-AR - Arrow Keys Mode (4-Key Models Only); Arrow up String (4-Key Models Only)

Enter/Exit Programming Mode
Product Reference Guide 255
Arrow Keys Mode (4-key models only)
Configure the Arrow Keys functionality type. Two options are available:
Function Keys Action Select mode: When in this mode, arrow keys are used to
select one of the 3 possible actions associated to the Function Keys. To
associate actions to the Function keys, see "Co
nfigure Actions for Function
keys" on page 257.
String Association Mode: When in this mode, each one of the arrow keys can
be programmed to display and transmit a pre-defined string (see
"Arrow Up
String (4-key models only)" on page 255
and "Arrow Down String (4-key
models only)" on page 256
).
Function Keys Action Select mode
DEFAULT
String Association Mode
Arrow Up String (4-key models only)
Associate a pre-defined string to the Arrow Up key
Set string for Arrow Up Key
To configure this feature, scan the ENTER/EXIT
PROGRAMMING MODE bar code above, then the bar
code at left.
Define the label string by further scan-
ning 32 digits from the Alphanumeric characters
in
Appendix D, Keypad .
The digits must be the hexadecimal ASCII represen-
tation of the desired characters; if less than the
ex
pected string of 16 characters are selected, scan
the ENTER/EXIT bar code to terminate the string.
End by scanning the ENTER/EXIT bar code again.
Make a mistake? Scan the CANCEL bar code to abort
and not
save the entry string. You can then start
again at the beginning.
CANCEL
