Product Reference Guide
321
Appendix B
Sample Bar Codes
The sample bar codes in this appendix
are typical repres
entations for their
symbology types.
1D Bar C
odes
UPC-A
EAN-13
97803302
9095
Code 39
Code 128
Code 128
Interleaved 2 of 5
330
332
